Arcade Cabinet Vault

Pac-Man 1980 classic upright arcade cabinet featuring original Namco yellow side art and illuminated marquee

Z80 ARCHITECTURE

Pac-Man (1980, Namco/Midway)

The flagship golden age cabinet running on a Zilog Z80 @ 3.072 MHz, 19-inch vertical CRT raster screen, and custom 4-way mechanical joystick.

View Pac-Man Hardware Manual

Galaga 1981 coin-operated arcade machine cabinet in dark arcade room

DUAL Z80 SYSTEM

Galaga (1981, Namco)

Dual Z80 microprocessor configuration, custom sound generators, horizontal dual-firing shooter controls, and iconic cabinet marquees.

Sega Astro City Japanese candy arcade cabinet control panel with microswitches

SEGA CANDY CABINET

Sega Astro City (1993, Sega)

The ultimate sit-down fiberglass Japanese arcade candy cabinet equipped with dual-frequency Nanao MS9 29-inch CRT screen and JAMMA standard wiring.

Atari Asteroids vector graphics CRT display screen in dark arcade room

ATARI QUADRASCAN

Asteroids Vector Cabinet (1979, Atari)

QuadraScan vector generator hardware, 6100 series vector CRT monitor chassis, high-voltage deflection transistors, and original button control pod.

Space Invaders original arcade coin door mechanism and coin drop details

INTEL 8080 CPU

Space Invaders (1978, Taito/Midway)

Groundbreaking 1978 upright cabinet featuring mechanical quarter acceptors, beam splitter mirror optical display, and discrete analog sound synthesis.

Vintage 1980s arcade side art vinyl application process on wooden cabinet

VINYL RESTORATION
